Non-Sparking Tools are the best alternative for non-sparking application purposes in potentially explosive environments. All tools are forget after casting to achieve the best quality in the market.

Caution!
These tools are not classified as anti-static because they do conduct electricity. Do not use high copper content tools (>65%) in direct contact with acetylene due to the possible formation of explosive acetylide, specially in the presence of moisture.

Al-Cu
Code S
mm

L
mm

WT
g

Code

S
inch

L
mm

WT
g

   15804001       22       55       330       15804401       1-1/16"       55       360
15804002 24 340 15804402 1-1/8" 364
15804003 25 345 15804403 1-3/16" 60 405
15804004 26 350 15804404 1-1/4" 431
15804005 27 360 15804405 1-5/16" 442
15804006 28 363 15804406 1-3/8" 448
15804007 29 365 15804407 1-7/16" 65 500
15804008 30 60 405 15804408 1-1/2" 560
15804009 31 410 15804409 1-5/8" 70 625
15804010 32 440 15804410 1-7/8" 75 740
15804011 34 455 15804411 2" 850
15804012 36 65 500 15804412 2-1/4" 80 1130
15804013 38 560 15804413 2-1/2" 90 1550
15804014 41 70 625 15804414 2-3/4" 1850
15804015 46 75 740 15804415 3" 95 2500
15804016 50 760
15804017 55 80 1160
15804018 60 85 1260
15804019 65 90 1580
15804020 70 1950
15804021 75 95 2430
15804022 80 2800
Be-Cu
Code

S
mm

L
mm

WT
g.

Code

S
inch

L
mm

WT
g.

15904001 22 55 361 15904401 1-1/16" 55 394
15904002 24 372 15904402 1-1/8" 398
15904003 25 377 15904403 1-3/16" 60 442
15904004 26 383 15904404 1-1/4" 470
15904005 27 394 15904405 1-5/16" 483
15904006 28 397 15904406 1-3/8" 490
15904007 29 399 15904407 1-7/16" 65 560
15904008 30 60 443 15904408 1-1/2" 620
15904009 31 448 15904409 1-5/8" 70 690
15904010 32 481 15904410 1-7/8" 75 850
15904011 34 497 15904411 2" 960
15904012 36 65 550 15904412 2-1/4" 80 1250
15904013 38 620 15904413 2-1/2" 90 1700
15904014 41 70 690 15904414 2-3/4" 2050
15904015 46 75 850 15904415 3" 95 2750
15904016 50 850
15904017 55 80 1160
15904018 60 85 1390
15904019 65 90 1750
15904020 70 2150
15904021 75 95 2680
15904022 80 3080
